http://example.com/foo/bar
)'),
'proto-rel' => t('Protocol relative URL (//example.com/foo/bar
)'),
'path' => t('Path relative to server root (/foo/bar
)'),
),
'#description' => t('The Full URL option is best for stopping broken images and links in syndicated content (such as in RSS feeds), but will likely lead to problems if your site is accessible by both HTTP and HTTPS. Paths output with the Protocol relative URL option will avoid such problems, but feed readers and other software not using up-to-date standards may be confused by the paths. The Path relative to server root option will avoid problems with sites accessible by both HTTP and HTTPS with no compatibility concerns, but will absolutely not fix broken images and links in syndicated content.'),
'#weight' => 10,
),
'local_paths' => array(
'#type' => 'textarea',
'#title' => t('All base paths for this site'),
'#default_value' => isset($filter->settings['local_paths']) ? $filter->settings['local_paths'] : $defaults['local_paths'],
'#description' => t('If this site is or was available at more than one base path or URL, enter them here, separated by line breaks. For example, if this site is live at http://example.com/
but has a staging version at http://dev.example.org/staging/
, you would enter both those URLs here. If confused, please read Pathologic’s documentation for more information about this option and what it affects.', array('!docs' => 'http://drupal.org/node/257026')),
'#weight' => 20,
),
);
}
/**
* Pathologic filter callback.
*
* Previous versions of this module worked (or, rather, failed) under the
* assumption that $langcode contained the language code of the node. Sadly,
* this isn't the case.
* @see http://drupal.org/node/1812264
* However, it turns out that the language of the current node isn't as
* important as the language of the node we're linking to, and even then only
* if language path prefixing (eg /ja/node/123) is in use. REMEMBER THIS IN THE
* FUTURE, ALBRIGHT.
*
* The below code uses the @ operator before parse_url() calls because in PHP
* 5.3.2 and earlier, parse_url() causes a warning of parsing fails. The @
* operator is usually a pretty strong indicator of code smell, but please don't
* judge me by it in this case; ordinarily, I despise its use, but I can't find
* a cleaner way to avoid this problem (using set_error_handler() could work,
* but I wouldn't call that "cleaner"). Fortunately, Drupal 8 will require at
* least PHP 5.3.5, so this mess doesn't have to spread into the D8 branch of
* Pathologic.
* @see https://drupal.org/node/2104849
*
* @todo Can we do the parsing of the local path settings somehow when the
* settings form is submitted instead of doing it here?
*/
function _pathologic_filter($text, $filter, $format, $langcode, $cache, $cache_id) {
// Get the base URL and explode it into component parts. We add these parts
// to the exploded local paths settings later.
global $base_url;
$base_url_parts = @parse_url($base_url . '/');
// Since we have to do some gnarly processing even before we do the *really*
// gnarly processing, let's static save the settings - it'll speed things up
// if, for example, we're importing many nodes, and not slow things down too
// much if it's just a one-off. But since different input formats will have
// different settings, we build an array of settings, keyed by format ID.
$cached_settings = &drupal_static(__FUNCTION__, array());
if (!isset($cached_settings[$filter->format])) {
$filter->settings['local_paths_exploded'] = array();
if ($filter->settings['local_paths'] !== '') {
// Build an array of the exploded local paths for this format's settings.
// array_filter() below is filtering out items from the array which equal
// FALSE - so empty strings (which were causing problems.
// @see http://drupal.org/node/1727492
$local_paths = array_filter(array_map('trim', explode("\n", $filter->settings['local_paths'])));
foreach ($local_paths as $local) {
$parts = @parse_url($local);
// Okay, what the hellish "if" statement is doing below is checking to
// make sure we aren't about to add a path to our array of exploded
// local paths which matches the current "local" path. We consider it
// not a match, if…
// @todo: This is pretty horrible. Can this be simplified?
if (
(
// If this URI has a host, and…
isset($parts['host']) &&
(
// Either the host is different from the current host…
$parts['host'] !== $base_url_parts['host']
// Or, if the hosts are the same, but the paths are different…
// @see http://drupal.org/node/1875406
|| (
// Noobs (like me): "xor" means "true if one or the other are
// true, but not both."
(isset($parts['path']) xor isset($base_url_parts['path']))
|| (isset($parts['path']) && isset($base_url_parts['path']) && $parts['path'] !== $base_url_parts['path'])
)
)
) ||
// Or…
(
// The URI doesn't have a host…
!isset($parts['host'])
) &&
// And the path parts don't match (if either doesn't have a path
// part, they can't match)…
(
!isset($parts['path']) ||
!isset($base_url_parts['path']) ||
$parts['path'] !== $base_url_parts['path']
)
) {
// Add it to the list.
$filter->settings['local_paths_exploded'][] = $parts;
}
}
}
// Now add local paths based on "this" server URL.
$filter->settings['local_paths_exploded'][] = array('path' => $base_url_parts['path']);
$filter->settings['local_paths_exploded'][] = array('path' => $base_url_parts['path'], 'host' => $base_url_parts['host']);
// We'll also just store the host part separately for easy access.
$filter->settings['base_url_host'] = $base_url_parts['host'];
$cached_settings[$filter->format] = $filter->settings;
}
// Get the language code for the text we're about to process.
$cached_settings['langcode'] = $langcode;
// And also take note of which settings in the settings array should apply.
$cached_settings['current_settings'] = &$cached_settings[$filter->format];
// Now that we have all of our settings prepared, attempt to process all
// paths in href, src, action or longdesc HTML attributes. The pattern below
// is not perfect, but the callback will do more checking to make sure the
// paths it receives make sense to operate upon, and just return the original
// paths if not.
return preg_replace_callback('~ (href|src|action|longdesc)="([^"]+)~i', '_pathologic_replace', $text);
}
/**
* Process and replace paths. preg_replace_callback() callback.
*/
function _pathologic_replace($matches) {
// Get the base path.
global $base_path;
// Get the settings for the filter. Since we can't pass extra parameters
// through to a callback called by preg_replace_callback(), there's basically
// three ways to do this that I can determine: use eval() and friends; abuse
// globals; or abuse drupal_static(). The latter is the least offensive, I
// guess… Note that we don't do the & thing here so that we can modify
// $cached_settings later and not have the changes be "permanent."
$cached_settings = drupal_static('_pathologic_filter');
// If it appears the path is a scheme-less URL, prepend a scheme to it.
// parse_url() cannot properly parse scheme-less URLs. Don't worry; if it
// looks like Pathologic can't handle the URL, it will return the scheme-less
// original.
// @see https://drupal.org/node/1617944
// @see https://drupal.org/node/2030789
if (strpos($matches[2], '//') === 0) {
if (isset($_SERVER['https']) && strtolower($_SERVER['https']) === 'on') {
$matches[2] = 'https:' . $matches[2];
}
else {
$matches[2] = 'http:' . $matches[2];
}
}
// Now parse the URL after reverting HTML character encoding.
// @see http://drupal.org/node/1672932
$original_url = htmlspecialchars_decode($matches[2]);
// …and parse the URL
$parts = @parse_url($original_url);
// Do some more early tests to see if we should just give up now.
if (
// If parse_url() failed, give up.
$parts === FALSE
|| (
// If there's a scheme part and it doesn't look useful, bail out.
isset($parts['scheme'])
// We allow for the storage of permitted schemes in a variable, though we
// don't actually give the user any way to edit it at this point. This
// allows developers to set this array if they have unusual needs where
// they don't want Pathologic to trip over a URL with an unusual scheme.
// @see http://drupal.org/node/1834308
// "files" and "internal" are for Path Filter compatibility.
&& !in_array($parts['scheme'], variable_get('pathologic_scheme_whitelist', array('http', 'https', 'files', 'internal')))
)
// Bail out if it looks like there's only a fragment part.
|| (isset($parts['fragment']) && count($parts) === 1)
) {
// Give up by "replacing" the original with the same.
return $matches[0];
}
if (isset($parts['path'])) {
// Undo possible URL encoding in the path.
// @see http://drupal.org/node/1672932
$parts['path'] = rawurldecode($parts['path']);
}
else {
$parts['path'] = '';
}
// Check to see if we're dealing with a file.
// @todo Should we still try to do path correction on these files too?
if (isset($parts['scheme']) && $parts['scheme'] === 'files') {
// Path Filter "files:" support. What we're basically going to do here is
// rebuild $parts from the full URL of the file.
$new_parts = @parse_url(file_create_url(file_default_scheme() . '://' . $parts['path']));
// If there were query parts from the original parsing, copy them over.
if (!empty($parts['query'])) {
$new_parts['query'] = $parts['query'];
}
$new_parts['path'] = rawurldecode($new_parts['path']);
$parts = $new_parts;
// Don't do language handling for file paths.
$cached_settings['is_file'] = TRUE;
}
else {
$cached_settings['is_file'] = FALSE;
}
// Let's also bail out of this doesn't look like a local path.
$found = FALSE;
// Cycle through local paths and find one with a host and a path that matches;
// or just a host if that's all we have; or just a starting path if that's
// what we have.
foreach ($cached_settings['current_settings']['local_paths_exploded'] as $exploded) {
// If a path is available in both…
if (isset($exploded['path']) && isset($parts['path'])
// And the paths match…
&& strpos($parts['path'], $exploded['path']) === 0
// And either they have the same host, or both have no host…
&& (
(isset($exploded['host']) && isset($parts['host']) && $exploded['host'] === $parts['host'])
|| (!isset($exploded['host']) && !isset($parts['host']))
)
) {
// Remove the shared path from the path. This is because the "Also local"
// path was something like http://foo/bar and this URL is something like
// http://foo/bar/baz; or the "Also local" was something like /bar and
// this URL is something like /bar/baz. And we only care about the /baz
// part.
$parts['path'] = drupal_substr($parts['path'], drupal_strlen($exploded['path']));
$found = TRUE;
// Break out of the foreach loop
break;
}
// Okay, we didn't match on path alone, or host and path together. Can we
// match on just host? Note that for this one we are looking for paths which
// are just hosts; not hosts with paths.
elseif ((isset($parts['host']) && !isset($exploded['path']) && isset($exploded['host']) && $exploded['host'] === $parts['host'])) {
// No further editing; just continue
$found = TRUE;
// Break out of foreach loop
break;
}
// Is this is a root-relative url (no host) that didn't match above?
// Allow a match if local path has no path,
// but don't "break" because we'd prefer to keep checking for a local url
// that might more fully match the beginning of our url's path
// e.g.: if our url is /foo/bar we'll mark this as a match for
// http://example.com but want to keep searching and would prefer a match
// to http://example.com/foo if that's configured as a local path
elseif (!isset($parts['host']) && (!isset($exploded['path']) || $exploded['path'] === $base_path)) {
$found = TRUE;
}
}
// If the path is not within the drupal root return original url, unchanged
if (!$found) {
return $matches[0];
}
// Okay, format the URL.
// If there's still a slash lingering at the start of the path, chop it off.
$parts['path'] = ltrim($parts['path'],'/');
// Examine the query part of the URL. Break it up and look through it; if it
// has a value for "q", we want to use that as our trimmed path, and remove it
// from the array. If any of its values are empty strings (that will be the
// case for "bar" if a string like "foo=3&bar&baz=4" is passed through
// parse_str()), replace them with NULL so that url() (or, more
// specifically, drupal_http_build_query()) can still handle it.
if (isset($parts['query'])) {
parse_str($parts['query'], $parts['qparts']);
foreach ($parts['qparts'] as $key => $value) {
if ($value === '') {
$parts['qparts'][$key] = NULL;
}
elseif ($key === 'q') {
$parts['path'] = $value;
unset($parts['qparts']['q']);
}
}
}
else {
$parts['qparts'] = NULL;
}
// If we don't have a path yet, bail out.
if (!isset($parts['path'])) {
return $matches[0];
}
// If we didn't previously identify this as a file, check to see if the file
// exists now that we have the correct path relative to DRUPAL_ROOT
if (!$cached_settings['is_file']) {
$cached_settings['is_file'] = !empty($parts['path']) && is_file(DRUPAL_ROOT . '/'. $parts['path']);
}
// Okay, deal with language stuff.
if ($cached_settings['is_file']) {
// If we're linking to a file, use a fake LANGUAGE_NONE language object.
// Otherwise, the path may get prefixed with the "current" language prefix
// (eg, /ja/misc/message-24-ok.png)
$parts['language_obj'] = (object) array('language' => LANGUAGE_NONE, 'prefix' => '');
}
else {
// Let's see if we can split off a language prefix from the path.
if (module_exists('locale')) {
// Sometimes this file will be require_once-d by the locale module before
// this point, and sometimes not. We require_once it ourselves to be sure.
require_once DRUPAL_ROOT . '/includes/language.inc';
list($language_obj, $path) = language_url_split_prefix($parts['path'], language_list());
if ($language_obj) {
$parts['path'] = $path;
$parts['language_obj'] = $language_obj;
}
}
}
// If we get to this point and $parts['path'] is now an empty string (which
// will be the case if the path was originally just "/"), then we
// want to link to Número de participantes: 15
Fechas:
Descripción y justificación
DAT0 P0R LIEBRE es un laboratorio teórico-práctico de visualización de información que busca analizar el desarrollo actual de la economía informal en Bogotá, específicamente en la zona de la Carrera 10 entre Avenida Jiménez (Calle 13) y la Calle 10, y la Calle 10 entre Carrera 10 y Carrera 9, en relación con las políticas de gobierno distrital sobre el ordenamiento de esta actividad y la recuperación del espacio público.
Mediante una preparación e interpretación de datos, prototipado y producción de proyectos, el laboratorio tiene como objetivo establecer una postura crítica sobre las dinámicas de la venta ambulante. En este proceso cada participante podrá explorar diferentes derivaciones del tema propuesto con el fin de generar diversos proyectos en colectivo. Como resultado se llevará a cabo una intervención física y digital en Plataforma Bogotá y en algún lugar del espacio público de la ciudad.
Durante los días de trabajo, los asistentes tendrán la oportunidad de colaborar y debatir entre sí para desarrollar distintos procesos de visualización en un entorno multidisciplinar. Las propuestas podrán realizarse en distintos formatos que pueden variar entre representaciones plásticas, audiovisuales, gráficas, sonoras, intervenciones en la web, programación, performance, etc.
El factor humano registrado y cuantificado a través de cifras, es ahora una fuente global de recursos de conocimiento, al servicio de sistemas corporativos e ideologías basadas en datos. Aunque es visible el uso de tal fuente (Open Data), su lectura está siempre determinada por la intención sesgada de quienes interpretan los datos, con afán de trazar vectores de información en tiempo real. Así gana quien presenta efectivamente ideas como realidades indiscutibles, con el ánimo de influenciar, a lo que conocemos como opinión pública.
La economía informal en Bogotá es un tema recurrente pero del que poco se conoce. Al día de hoy no se tiene una claridad sobre sus dinámicas, lo que ha dificultado entender la manera sobre cómo podría aprovecharse la misma para el beneficio de la ciudad. En muchas ocasiones las actividades que se desarrollan bajo este tipo de economía son consideradas como un tipo de “invasión” y no como un fenómeno cultural de desarrollo económico, que responde al contexto social de sus habitantes.
La intención al desarrollar un Laboratorio para visualizar información en Bogotá, es establecer un espacio colaborativo de aprendizaje que propicie el uso de representación de datos; donde se experimente con información cuantificable. Así, los artistas, diseñadores, visualizadores, ingenieros, programadores, desarrolladores, investigadores, asistentes y demás involucrados podrán evidenciar con sus proyectos el nivel de percepción reflejado en la opinión propia y del resto de los actores que conforman el tejido social.
DAT0 P0R LIEBRE ofrece a los participantes una mirada honesta de las estrategias de difusión y manipulación de información presentes en lo cotidiano. El compromiso es entender que la visualización no solo define la posición relativa de los datos, sino la del visualizador mismo durante el proceso de traducción de información.
Resultados esperados
Generar una investigación y de tratamiento de datos que documente y visualice los procesos de transformación de la economía informal en la ciudad de Bogotá, específicamente en la zona de la Carrera 10 entre Avenida Jiménez (Calle 13) y la Calle 10, y la Calle 10 entre Carrera 10 y Carrera 9, desde junio de 2014 hasta junio de 2016. Como resultado final, el laboratorio plantea una intervención plástica y digital en Plataforma Bogotá y en un lugar del espacio público de la ciudad, esta última sujeta a la disposición de los participantes, que permita la interacción de personas de diferentes edades, condiciones sociales y ámbitos inter y transdisciplinares.
Objetivos
Metodología y descripción general de las sesiones
01. Preparación de datos: 6 de julio
a. Fuentes de información
Base de datos. Compilación, indexado y depuración de información.
b. Análisis de Datos
Estructura de la información.
c. Filtrado de datos
Transformación de información.
Preparar datos en bruto para una visualización efectiva, es de los principales focos de interés en la visualización de la información.
Mediante la manipulación de datos, se puede apreciar cómo se ve afectado el mensaje visual.
Los primeros experimentos de este módulo, ayudan a comprender el impacto de la transformación de datos en la comunicación. Por ejemplo, al incluir o excluir datos específicos de la fuente de información.
02. Interpretación de datos: 7 y 8 de julio
a. Representación gráfica
Diagramas y lenguaje gráfico.
b. Discusión de resultados
Definición de mensaje basado en resultados.
Mediante una representación simbólica de información se puede simplificar la comunicación de un texto, un dato o una narración para facilitar su entendimiento.
Con lo ejercicios y ejemplos de este módulo se pretende comparar, contrastar y señalar diferencias en la información. Explicar causalidad, subrayar mecanismos, dar explicaciones y poner en evidencia patrones sistemáticos. Documentar fuentes, indicar escalas de medición completas y subrayar los puntos relevantes.
03. Prototipado: 9 de julio
a. Mapa mental
Lluvia de ideas y extracción de información.
b. Narrativa
Conceptualización y Storytelling.
c. Propuesta definitiva
Maquetación, simulación y Presentación de idea.
Un mapa mental es una buena herramienta para desplegar el análisis e interpretación de datos, porque puede capturar en un espacio reducido gran cantidad de información que permite ver las conexiones entre datos e información contrapuestos.
En este módulo se pretende dar forma a un proyecto basado en datos, desarrollando un concepto, un lenguaje y una propuesta de presentación.
04. Laboratorio de medios: 11, 12, 13, 14, 15, 18 y 19 de julio
a. Taller de producción
Experimentación con medios, materiales, formatos, escenarios, etc.
b. Programación y electrónica creativa.
Visualización generativa, dispositivos, sistemas automáticos.
c. Documentación
Registro video-fotográfico para exhibición y difusión.
Un laboratorio de investigación y difusión de los proyectos definitivos, con la idea de experimentar y aprender colaborativamente.
Se trata de un espacio de producción de visualizaciones pensadas como objetos físicos, proporcionando a los participantes herramientas de fabricación digital o analógica, para aprender por sí mismo o en cooperación con otros.
¿Cómo participar?
Criterios de selección:
Motivación y aportes en investigación y formación con relación a las problemáticas del laboratorio. Interés por la visualización de información y tratamiento de datos.
*Nota: De ser posible traiga un computador portátil a las sesiones del laboratorio.
Reactante + La Loma
Invitados especiales: Gabriel Zea, Daniel Suárez y Mauricio Fino-Garzón
Reactante (Andrés Stepanichtchev // Laura Criollo Carrillo)
Reactante es un agente catalizador y generador de prácticas alternativas enfocadas a la experimentación, investigación, creación y visibilización de procesos que interrelacionan el arte, la ciencia y la tecnología en Colombia.
Estas prácticas alternativas tienen su origen en un ejercicio de detección y análisis de tendencias transdisciplinares, nacionales e internacionales, cuya visión vanguardista se orienta a impulsar relaciones colaborativas y de intercambio, basadas en lazos de confianza.
Reactante está dirigido a un grupo diverso y multigeneracional de artistas, creadores e impulsores de proyectos, instituciones y empresa privada, interesados en el arte, la ciencia y la tecnología.
http://reactante.blogspot.com.co/
La Loma (Daniel Desiderio Páez Castillo // Julia Wolf)
La plataforma/colectivo La Loma es el punto de encuentro de Daniel Desiderio Páez Castillo y Julia Wolf en Berlín - Alemania, quienes se interesan en investigar y desarrollar estrategias para visualizar información.
En La Loma se intenta entender el tejido de la realidad, como un paisaje observado a través de datos. Una montaña de información en constante cambio, rica en accidentes topográficos. Una zona a seguir desde distintos puntos, desde la cima con vista amplia o a distancia describiendo su magnitud, para documentar una imagen honesta y solidaria con este paisaje.
http://laloma.info
Asistencia en investigación, gestión y logística: Lina Pulido y David Barreto.
